CAT NO: DIDACTICNLE-Export-081150
Universal Embedded Trainer.
Single board embedded kit based on ARM, AVR, 89CXX, PIC microcontroller for any embedded applications.
Feature
01. Daughter CPU Boards for
Philips 89C61X2 microcontroller.
Microchip PIC 16F877A microcontroller.
Microchip PIC 18F452 microcontroller.
Philips ARM LPC 2148 microcontroller.
ATMEL ATmega32 microcontroller.
02. ISP Programming facility for all microcontroller.
Onboard Applications
01. 16 LED’s to display digital output.
02. 16 switches to give digital input indicated by LED’s.
03. 16x2 alphanumeric LCD backlit display.
04. 4x4 matrix keyboard.
05. miniature buzzer.
06. 12V SPDT Relay.
07. 4 digit seven segment displays.
08. I2C compatible:
24C512 EEPROM (64KB).
RTC with suitable battery.
4Ch. 8bit ADC & 1Ch. 8 bit DAC using
09. Temperature sensor interface using
10. Temperature sensor interface using
11. 24 I/O Lines Provided on a 26 pin FRC connector for external interface.
13. On board supply +/- 12V, 5V, 3.3V, 2.5V, 1.5V & 1.2V is provided.
14. Supply Input Voltage: 230V AC.
15. All ICS are mounted on IC Sockets.
16. Bare board Tested Glass Epoxy SMOBC PCB is used.
17. Attractive Wooden enclosures of light weight australian pine wood.
18. User's manual with `C’ source code sample programs for all on board applications.
