Soldering Machine

Soldering Machine

CAT NO: DIDACTICModel No NCI102

Soldering Machine Description and Tender Specification:

Soldering Machine.
Soldering machine
Heating Method Pulse heat
Power requirement 220V AC 50/60HZ 2KVA
Operating Ambient 23-40c
System type table tab
Pulse Heating Specification
Temperature ramp Profile 4 stages
Preset Start Temperature 30c to 300c
Preset Ramp Temperature 30cto 450c
Preset Release temperature 30-450c
Preset hold period 1-100seconds
Ramp Period 1-25 seconds, term ode specification, Bonding force 1kgf-40kgf, thermocouple type K type
Maximum thermode size 55mmX3MM
Dimension 700mm(L) X600mm(W)x480mm(D)
KIRSTEN soldering AG
( KIRSTEN hollow jet-wave soldering machine, type K5000/K7000)
