CAT NO: DIDACTICNLE-Export-081113
Single Phase Energy Meter Trainer.
Single Phase Energy Meter Trainer for Electrical Labs and Electrical Engineering Training Equipments Single phase energy meter trainer describes
a high accuracy, low cost, single-phase energy meter. The meter is
designed for use in single-phase, 2-wire distribution systems. The
design can be adapted to suit specific regional requirements, e.g., in
USA, power is usually distributed for residential customers as single
phase, 3-wire. This is a highly integrated system comprised of two
ADC's, a reference circuit, and a fixed DSP function for the calculation
of real power. A highly stable oscillator is integrated into the design
to provide the necessary clock for the IC. This includes direct drive
capability for LCD Display and a high frequency pulse output for
Calibration.
Features :
Complete training system for in depth study of single phase energy meter .
Micro controller based LCD display.
The
display acts as a counter of units consumed as well as it shows the
wattage of load and the time since the system has been On.
Easy diagrammatic representation of Energy Meter.
Test points are provided to measure the voltages at different points.
Low Cost Trainer with high accuracy, demonstrating all the basic concepts of Single Phase Energy Measurement.
Good quality, reliable sockets are provided at appropriate places on board for electric board supply and load connections.
Designed with considering all safety standards.
Provided with an extensive e-manual.
Technical Specifications :
Line Voltage : 230V AC ±10%, 50 Hz
Meter Constant : 1600 impulses/KWh (On LED)
Display Counter : 100 impulses /KWh (On LCD)
Maximum Current : 30 A
Shunt : 350 mW
Scope of Learning :
Study the application of Single Phase Energy Meter for measurement of Power Consumed.
Study of Single Phase Energy Meter using different test points and to understand its working
