CAT NO: DIDACTICNLE-Export-202456
Security Alarm Trainer.
Security alarm trainer Salient Features : Has built in standby batteries
to demonstrate working of system in case of mains supply failure.
Facilitate hands on training through use of 4mm patch cords by
constructing FAT circuits using various fire detectors.
Each panel has ABS molded plastic sturdy enclosure, and colorful screw
less overlays showing circuit diagram & its connection tag nos. for
easy understanding & connections.
Provides real time simulations and activation of the fire alarm control
system.
Set of Instructor Guide & Student Workbook
TECHNICALSPECIFICATIONS A] Aluminum profile rack (5x4) sturdy flat demo
panel (table top) system carrying various components housed in plastic
enclosures (panels) to minimize shock possibility, in top three rows.
The bottom row holds control panel with batteries. u 1 Phase AC Input
Supply Panel (EMT16A) u Smoke detector panel (FAT1) u Heat detector
panel (FAT2) u Manual Call Point (MCP) panel (FAT4) u Siren with flasher
panel (FAT5) • 1 ph.dual MCBs of 2A for short circuit protection •
Photoelectric smoke sensor • Operating voltage – 12VDC • Standby current
– 20uA • Alarm current – 35mA@12VDC • Alarm output – Remote LED •
Temperature range – 0% ~ 95%RH • Operating voltage : 12VDC • Static
current : < 95% RH • Detecting range:50 square meter with the
installation height of 6m: 12m • Operating voltage : 12VDC • Resettable
type : MCP • Active/ de active LED indication • Push to activate &
deactivate by plastic key • Operating voltage : 12VDC@500mA • Power : 6W
• Sound level : 105dB • Flashing rate : 150 per minute u Gas (LPG) Leak
detector panel (FAT3) u Control panel (FAT6) u List of Experiments u
Mechanical Dimension (mm) / Weight • Operating voltage : 12VDC • Relay
output contacts with max : 24V@1A • Inbuilt alarm indication buzzer 0 •
Inbuilt heat detector (trip point 60 C) • Supply voltage : 230VAC
+/-10%/ 50Hz/max 2W • 12VDC (6V,4.5A x2nos) rechargeable battery backup •
Zone indication : Fire detection, sensor open, sensor short, sensor
bypass & zone test indication • Status indication– system ON, fire
indication, reset key hit, silence key hit, zone fault & siren ON •
Fault indication : AC fail, Hooter fail, Battery low • 5 keys keypad •
Keypad enable/desable by key lock • Relay output for siren with max :
24VDC@5A 0 • Operating temperature : 0 to50 C, CAD/CAM LABORATORY EQUIPMENTS, educational cnc milling machines manufacturers, educational cnc LATHE machines manufacturers, Strength of Material Testing equipment supplier, mechanical engineering laboratory equipments suppliers, soil, bitumen, concrete testing, civil engineering laboratory equipments suppliers
