Lighting installation

Lighting installation

CAT NO: DIDACTICECE-LAB-0104

Lighting installation Description and Tender Specification:

Lighting installation.
Lighting of a hotel room
• Lighting of a filing room from 3 points
• Time switch of a staircase lighting
• Electrical installation for a flat
• Lighting controlled by electronic touch-sensitive switches
from 2 points
• Lighting controlled by electronic touch-sensitive switches
from more than two points
• Lighting controlled by light dimmer
TECHNICAL SPECIFICATIONS
The set of modules to carry out lighting electrical installations  consists of:
1 Module type AZ-1
2 Switches for domestic uses
1 Module type AZ-2
1 Switch for domestic uses
2 Modules type AZ-3
2 SPDT switches for domestic uses
1 Module type AZ 4
2 Inverters for domestic uses
2 Modules type AZ-5
2 Pushbuttons for domestic uses
1 Module type AZ-6
1 Pulse relay (230 V-coil)
1 Module type AZ-7
1 Sequence relay (24-V coil)
3 Modules type AZ-8
2 Lamp-holders with lamps (230 V)
1 Module type AZ-9
1 Single-phase outlet – 230 V – 10 A
1 Module type AZ-9a
1 Single-phase outlet – 230 V – 16 A
1 Module type AZ-10
5 Fuse-holders with sectionable fuses 4/6 A
1 Module type AZ-11
1 Choke for fluorescent lamp
1 Module AZ-12÷13
1 Capacitor and starter for fluorescent lamp
1 Module type AZ-14
1 Fluorescent lamp with holder
1 Module type AZ-15
1 Transformer 115-230 / 12-24 V – 50-60 Hz – 72 VA
1 Module type AZ-34
1 Time relay (230-Vac motor) for staircase lighting
2 Modules type AZ-35
1 Light pushbutton for staircase with neon glow lamp 230 V
1 Module type AZ-39
1 Light dimmer, 500 W – 230 V
1 Module type AZ-40
1 Electronic touch-sensitive switch, 500 W – 230 V
Supplied accessories
Set of 50 cables with Ø 4 mm safety pins
GENERAL POWER SUPPLY
230 V / PE – 50-60 Hz
THEORETICAL-EXPERIMENTAL HANDBOOKS
Application handbook with exercises
