Embedded Trainer For Electrical Lab Training

Embedded Trainer For Electrical Lab Training

CAT NO: DIDACTICNLE-Export-081149

Embedded Trainer For Electrical Lab Training Description and Tender Specification:

Embedded Trainer.
Single board universal embedded kit based on MCU (Philips 89C61X2) microcontroller for any embedded applications. Feature: 01. CPU: Philips 89C61X2 microcontroller 02. ISP programming facility Onboard application: 01. 8 LEDs to display digital output 02. 8 Switches to give digital input each indicated by LED 03. 16*2 alphanumeric LCD 04. 4 digit seven segment displays 05. I2C compatible       - 24C512 EEPROM (64KB)       - DS1307 RTC with suitable battery       - 4 Ch. 8bit ADC & 8 bit DAC using PCF 06. Temperature sensor interface Lm35 07. Temperature sensor interface DS18B20 24 I/O Lines 08. 24 I/O Lines Provided on a 26 pin FRC Connector for external interface 09. On board supply +/- 12V, 5V is provided 10. Supply input voltage: 230V AC 11. User's manual with sample programs for all on board features
