CAT NO: DIDACTICNLE-Export-202093
Digital Compression Hydraulic Testing Machines. /for Building Material.
Digital compression hydraulic testing machines. /for Building material/
Application- Compression testing machines are mainly used to various
materials compression test .Such as cement, concrete, brick of diverse
materials, rubber tray, concrete component, metal components.
Features :-
� high performance load frame, with high stiffness and stability.
� Hydraulic loading, wide speed adjusting range.
� Digital display, testing load, speed, peak value.
� With over load, over voltage, over current protection functions.
Specifications :-
-max load capacity 300 KN (kilo newton).
- Measuring force range 6KN- 300 KN.
- Accuracy of testing force ± 1% of induced value.
- Piston stroke 80mm
- - piston diameter Ø 125mm
- - Compression space 230 mm
- - Compression platen diameter Ø155mm.
- - Power supply 380 ±10%, 50 HZ, 3 phases 0.75KW.
- -Dimensions 850 X 620 X 1340 mm
- - Weight 400Kg.
