CAT NO: DIDACTICNLE-Export-220345
Determination Of Cd, Cv And Cc Orifices- Engineering Lab Training Systems.
Overhead tank 45x45x120 cms high is strongly made in steel sheet and
angle iron frame with separating pipe, gauge 'glass and scale graduated
In cms and litres, drain cock and overflow. The tank has quick action
valve in front having a facing to take the follow interchangeable
orifices which are included with the apparatus. Four orifices sharp
edged-round, square, rectangular and rectangular and four mouth
pieces, convergent, divergen 111 form and re-entrant.
(b) Stand for above made of angle Iron and Iron strips stror4l; made.
(c)
Scale and Sliding Attachment For measuring the curved the out flowing
jet. Horizontal and vertical scales are accurate to 1 mm with vernier
reading to 1/10 mm. Complete with fix arrangements to the overhead tank.
(d)
Collecting tank For above, size 8OX80x90 cm in strong steel sheet and
angle iron frame work. Complete with a glass gauge and scale calibrated
In cms and litres and also a quick drain cock.
(e) Collecting
Tank Size 80x80x90 cm In strong steel sheet and angle iron frame work
divided Into two water light com partments each having a gauge glass and
scale calibrated , cms and litres and also a quick drain cock.
