CAT NO: DIDACTICNLE-Export-202091
Destructive Weld Tester.
Destructive weld tester The Weld Tester is a destructive weld testing
machine that incorporates compression, tensile, and bend testing in one
complete unit. The W-50 is an invaluable asset to any training facility
or commercial company that requires weld qualification.
The W-50 can do all the destructive tests as specified by AWS, ASME, and
API. The W-50 requires very little space since the unit sits
horizontally. This machine is designed so the entire test procedure can
be handled by one operator quickly and easily.
Test capability
FULL PIPE TENSILE TEST - Up to 1.5" Std. Pipe. Compress (flatten) pipe
coupon ends to be held by thebinding jaws. Tensile (pull) up to 50,000
lbs.
between the two jaw sets. Maximum coupon length 12 inches.
NICK-BREAK TENSILE TEST - Either pipe or flat bar can be forced to break
by 'nicking' the weldment at the intended break line. This is a visual
evaluation test.
GUIDED ROLLER BEND TEST - All bend tests are possible (Root, Face, Side
Bends). Two bend test diameters are supplied. The 1.5" Diameter plunger
tests coupons up to .375" x 2" x approx. 8" with a material yield
strength of 50K PSI or less. The 3.5" Diameter Collet over the plunger
tests coupons up to .50" x 2" x approx. 8" with a material yield
strength of 80K PSI or less.
Dimensions:5' X 10" X 20"
HShipping Weight:410 lbs.
Volts/Amps:115/12.8
Horsepower:one
Max. pull:50,000 psiMax. coupon length:12 inches
