DC Series Motor Lab.
DC Series Motor Lab is a very useful product
for any electrical Laboratory to demonstrate the fundamental concepts
and operating principles of DC machines. It is useful for students to
enhance their practical knowledge which enables complete learning.
Demonstrates, operating characteristic of DC Series Motor. Students can
get aware of the methods through which the speed of the DC Series Motor
can be controlled. It includes terminals for Rheostat and Starters so
that these devices can be connected externally to the panel. All
connections and panel ergonomics are designed in such a manner that
students can make connections by themselves. All protection devices are
in built eliminating chances of fault or danger to user.
Stand alone operation
Exclusive and attractive designed panel
High quality meters
Designed by considering all the safety precautions
Safety terminals and patch chord package.
Mechanical loading arrangement
e-Manual
Scope of Learning
Study of Operating Characteristics of Separately Excited DC Series Motor
Study of Speed Control of Separately Excited DC Series Motor using Field Current Control
Study of Speed Control of Separately Excited DC Series Motor using Armature Voltage Control
Technical Specifications
Input : 0 - 180 V Variable DC
Machine Specifications
Type : DC Series
Voltage rating : 180 V
Current rating : 3 A
Power Rating : 1 HP
RPM : 1500 R.P.M
Meters used
Voltmeter (MC) 1 No. : 300 V
Ammeter (MC) 2 Nos. : 5 A
Dimensions (mm) : W 350 × D 600 × H 450
