Capping Set (Horizontal)- Engineering Lab Training Systems

Capping Set (Horizontal)- Engineering Lab Training Systems

CAT NO: DIDACTICNLE-Export-220238

Capping Set (Horizontal)- Engineering Lab Training Systems Description and Tender Specification:

Capping Set (Horizontal)- Engineering Lab Training Systems.
This is for capping test cylinders and core for compression testing. It can be used both in the laboratory and the field. The set comprises a cylinder capper, a cylinder carrier and a ladle. The cylinder capper consists of a base on which two accurately machined plates are mounted. One plate is firmly  fixed and the other one is adjustable horizontally. Two plates are provided with holders for holding the cylinder In position. The holders are split and the bottom half of each holder is fixed firmly and the top half of each is removable and bolted down to the lower half. On the upper parts V-is provided for pouring the capping compound. Two spacers are also provided. The cylinder carrier is used for carrying the cylinder from the storage tank to the capper and back. The ladle is for pouring te molten capping compound into the V of the capper while capping a concrete cylinder. For specimens 15 cms dia x 30 cms long.
