.jpg "Brushless DC Motor With Controller (BLDC) For Electrical Lab Training")
CAT NO: DIDACTICNLE-Export-081135
Brushless DC Motor With Controller (BLDC).
BLDC Motors as the name suggests are brushless DC motors,
these motors have commutation with the help of electronic controllers.
These motors have advantage of conventional motors of zero maintenance,
but have a complex electric circuit for the same. The efficiency of the
motors is high & find applications in various medical appliances
& railways carriage fans. This Model is the industrial/educational
model suitable for demonstrating to students the complete know of the
basics, components, starting methods, speed control, wear & tear
& maintenance of these motors packaged in small rating. Students can
make connections of their own with the help of the terminations
provided for study of features viz starting methods, speed control,
speed-torque, effects of armature voltage, motor operation.
Technical Specs :
Power ratings available : 60W
Voltage Input: 24V DC
RPM: 1500
Single shaft extension,
List Of Experiments:
Electronic commutation
Speed Control & Over speed operations
Load test & No load test of machine
Speed-Torque Analysis
Voltage-Speed Analysis
Efficiency Analysis
Cold Resistance & Hot Resistance
Motor Operation parameters
Generator Operation parameters
Basic Overhauling Know how
