CAT NO: DIDACTICNLE-Export-119001
40 Pin Universal Programmer For Electrical Lab Training.
FEATURES
· 40 Pin DIP ZIF socket
· Printer Port Interfaces, parallel communication, uses address 278H,378H, 3BCH
· Easy interface to LAPTOP, PC, PS/2 or compatibles.
· Mouse support, user friendly menu driven software interface.
· High speed programming, Cost effective Hardware and Flexible Software.
· Tests standard logic and SRAM devices
· Supports DOS and Windows XP/2000/NT/ME/9x.
· Free software update from internet.
SPECIFICATION
· AC adapter : Input 100V- 240V AC, Output 12VDC/2Amp.
· Dimension : 200(L)x140(W)x24(H)mm
DEVICE SUPPORT
Supports more than 3450 devices, including :
· Most E(E)PROM, Series E(E)PROM. Flash.
· GAL, EP3xx/6xx/9xx, PEEL, PALCE, TIBPAL, PLUS, PLS, PLH, PLC, ATV, ATF, CPL, 85Cxxx, 5Cxxx, DS12xx.
·
Microcontrollers 87xx / 89xx / Z86Exx / TMS320xxx / D77Pxx / D75Pxx /
D78Pxx / PD75xxx / HD6370xxx / PIC16Cxx/17Cxx, COP87xx, and PSD3XX.
· TTL TESTER : 74 SERIES
· CMOS TESTER : 40/45 SERIES
· MEMORY TESTER : 2K/8K/32K STATIC RAM
HARDWARE & ELECTRICAL SPECIFICATIONS
· Device socket : One 40 pin ZIF socket.
· Programmer dimensions: 7 3/4" L x 5 1/2" W x 3/4" H.
· Power supply : Input AC 100 to 240V , Output : DC 12V/ 1.5Amp.
