CAT NO: DIDACTICNEL0014
CHNS/O Elemental Analyzer.
CHNS/O Elemental Analyzer 0 – 100 % Accuracy: < 0.3 % Analysis Time: Mode Time (minutes) CHNS 10 or lesser OXYGEN 5 or lesser Gases required: Carrier : - Helium (purity - 99.995% or better) Combustion : - Oxygen (purity- 99.995% or better) Max. Furnace temp:1000 0C or more Sample type: Solid and liquid Electronic Auto sampler: Capable of holding 30 samples or more
ï€ Liquid autosampler- Min. 7 place or more [for direct injection of liquid samples] Software: Main features of software:-
ï€ Windows based software
ï€ Permanent display of all parameters for continuous monitoring of EA operation
ï€ Data export to MS-Excel format Automated Gas Saver: Automatic leak test of gases and automatic standby of analyzer Detector: Thermal Conductivity Detector Ash removal assembly: Provision for Ash and Residual removal without extracting the reactor from furnace Gas regulators: Two nos.- one each for Helium and Oxygen; made up of Stainless Steel Analysis kit CHNS: analysis kit (tin capsules, Standards, Water traps, quartz wool, GC packed column) for 2500 samples or more OXYGEN analysis kit (silver capsules, standards, Nickel/quartz wool, Nickel plated carbon, traps, GC packed column) for 1000 samples or more Minimum PC requirement: Compatible Branded Personnel Computer with licensed Windows OS and laser jet printer Micro balance: 01 No. ( Ultra Micro Balance interfaciable with Computer, six place or more accuracy, 1 μg or lesser resolution and calibration certificate) Spare Parts: Standard parts (fittings, fuses, o-rings, tubing etc.) for trouble free operation for three years Tool kit: 01 No. (Spanners, Allen keys, screwdrivers, Spatula etc.) Power requirement: Single phase, 220 V, 50 Hz Manuals - Operation , Service & User Manuals to be supplied Availability of consumables & spare parts - Supply of consumables, Spares, accessories for at least (10) years to be assured Warranty: must have warranty Installation & Training – Installation and training for three days at DLJ
